Welding inverter GeniMig® 240DP SET1Q (MIG/MAG/LiftTIG/MMA)
Code: KWXSTGM240DP_S01Q
_en.png?678531f8)
Related products
Product detailed description
WARNING: From serial number 20240500001 (i.e. production May 2024) the power supply is equipped with SMART FAN function - temperature sensor switches the fan only when the internal temperature reaches 40~45°C.
GeniMig®240DP LCD power supplies are modern inverter welding power supplies offering very high welding versatility. Their main advantage is the possibility of welding with single or double pulsed current in MIG or MAG mode. Thanks to modern IGBT technology and high quality components, it is the ideal device for every welder.
KOWAX® brand product, with full technical support and express service in the Czech Republic!
Reliability, professionalism, wide range of applications Double pulse, Pulse, Short circuit, welds:
Steel (Short/Pulse)
Stainless steel (Short/Pulse)
Aluminum (Double Pulse)
Three processes in one device (3in1):
MIG/MAG DC;
TIG LIFT DC;
MMA DC,
IGBT Inverter
Single phase input ~1x230V+/-10%
Synergy
Short circuit, Pulse, Double Pulse
3.5 inch color LCD display
Graphical LCD interface in Czech, English, German, Polish, Russian
Adjustable choke (arc characteristic control - soft/hard)
2T/4T and S2T/S4T
4 Feeding roller feeding
Coils 200mm/5kg, 100mm/1kg
Digital control
Memory function: 18 channels for recording
Overcurrent and overtemperature protection
Low noise - main cooling fan with STOP function when the electric arc is not burning.
FREE:
MIG torch 240A QUARTO 4m ( steel liner)
4m Teflon Liner is included
KOWAX® KWX3 auto-darkening helmet .
KOWAX® KOWAX® KWAX® CO2 gas regulator
3m 25mm2 cable with electrode holder 300A - 35-50
3m 25mm2 cable with earth clamp 300A - 35-50
Feeding rollers:
Steel/Stainless steel (V-shape) 0,8/1,0mm (in Feeder)
Aluminum (U-shape) 0.8/1.0mm included
Gas hose incl. clamp
Manual
Warranty Card.
|
Parameter\Model |
KOWAX® GeniMig®240DP LCD |
||||
|
Mains voltage |
1~230±10%, 50/60Hz |
||||
|
MIG |
TIG |
MMA |
|||
|
Output current range [A] |
40-200 |
20-200 |
30-200 |
||
|
No-load voltage [V] |
65 |
||||
|
Rated input power [kVA] |
8,2 |
||||
|
Load capacity [A] (40℃ 10min) |
60% 200 |
60% 200 |
60% 200 |
||
|
Effect |
0,93 |
||||
|
Protection (slow motor circuit breaker, characteristic C) |
16A/1f |
||||
|
Welding wire diameter [mm] |
0,8/1,0 |
||||
|
Wire feed speed [m/min] |
2-15 |
||||
|
Type of Feeder |
4-poster |
||||
|
Cover class |
IP21S |
||||
|
Application class |
F |
||||
|
Dimensions d x w x h [mm] |
460 x 220 x 375 |
||||
|
Weight [kg] |
15,6 |
||||
Additional parameters
| Category: | GeniMig® 240DP QUATRO torch |
|---|---|
| Weight: | 25.075 kg |
| EAN: | 0796554470597 |
| Metody svařování: | MIG/TIG/MMA |
| Síťové napětí: | 1x230 |
| Jištění: | 16A/1f |
| Průměr drátu: | 0,8/1,0/(1,2 Al pouze) |
| Průměr elektrody: | 2,0 - 5,0 |
| Napětí naprázdno: | 65 |
| Jmenovitý příkon MIG: | 8,2 |
| Hmotnost zdroje: | 15,6 |
| Zatěžovatel MIG（40℃,10 minut） 60%: | 200 |
| Zatěžovatel MIG（40℃,10 minut） 100%: | 155 |
| Minimální proud: | 20 |
| Maximální proud: | 200 |
| Rozměry d x š x v: | 460 x 220 x 375 |
| Hmotnost (netto): | 15,6 |
